Description
Product Name: 140G-H15I3-D16 Allen Bradley Output module
Product details:
The Allen-Bradley 140G series Molded Case Circuit Breakers (MCCBs) are designed to provide circuit protection in industrial and commercial applications. The part number 140G-H15I3-D16 structure indicates the following:
| Code Segment | Description | Likely Interpretation |
| 140G | Product Series | 140G Molded Case Circuit Breaker |
| H | Frame Size | H-Frame (Typically associated with a higher amperage range, e.g., up to 150 A or 250 A) |
| 15 | Amperage Rating | May indicate the maximum current rating of the frame (e.g., 150 A or 250 A) |
| I | Interrupting Rating | Indicates a specific level of short-circuit interrupting capacity (e.g., Standard, High, or Very High). |
| 3 | Number of Poles | 3-Pole (for three-phase circuits) |
| D16 | Trip Unit Rating | Indicates the specific continuous current rating of the trip unit, likely 160 A (160 Amps) |
Estimated Product Parameters (Based on 140G H-Frame)
| Parameter | Estimated Value/Range |
| Product Type | Molded Case Circuit Breaker (MCCB) |
| Frame Size | H-Frame |
| Number of Poles | 3-Pole |
| Rated Current ($I_n$) | 160 Amps (A) |
| Rated Operational Voltage ($U_e$) | Up to 690V AC (Voltage tolerance is market-dependent) |
| Rated Insulation Voltage ($U_i$) | Typically 750V or 1000V AC |
| Interrupting Capacity ($I_{cu}$) (kA) | Varies depending on the ‘I’ code, often in the range of 35kA to 100kA at 400/415V AC. |
| Trip Unit Type | Typically Thermal-Magnetic or Electronic (Microprocessor-based). The ‘D’ in D16 often suggests an Adjustable Thermal, Fixed Magnetic trip unit. |
| Trip Functions | Overload protection (Thermal), Short-Circuit protection (Magnetic) |
| Mounting | Panel/Backplate Mount |
Product Advantages (General for 140G MCCBs)
- High Interrupting Capacity: Designed to safely interrupt high short-circuit currents, ensuring system and personnel safety.
- Modular and Compact Design: Saves panel space and facilitates easier installation and maintenance.
- Wide Range of Accessories: Compatibility with auxiliary contacts, shunt trips, undervoltage releases, and motor operators for enhanced control and monitoring.
- Flexibility in Protection: Available with both thermal-magnetic and electronic trip units, allowing for precise and adjustable overload and short-circuit settings.
- Global Standards Compliance: Designed to meet major international standards (e.g., IEC, UL, CSA), making them suitable for global use.
- Coordination Capabilities: Engineered for selective coordination with downstream devices, minimizing power outages to affected sections only.
Precautions (Important Considerations)
- Proper Sizing: The MCCB must be correctly sized based on the maximum continuous load current and the available short-circuit current at the point of installation. Do not exceed the 160A trip rating.
- Interrupting Rating Check: Ensure the MCCB’s Interrupting Capacity ($I_{cu}$) is equal to or greater than the maximum potential short-circuit current at the installation location.
- Torque Specifications: Always follow the manufacturer’s specified torque values for terminal connections. Loose connections can lead to overheating, arcing, and failure.
- Use Approved Accessories: Only use Allen-Bradley/Rockwell Automation approved accessories (e.g., terminal shields, lugs, trip units) to ensure proper fit and performance.
- De-rating: MCCBs may need to be de-rated (operated below their nominal rating) in high ambient temperature environments or when multiple breakers are mounted in close proximity. Consult the product manual’s de-rating curves.
- Safety Procedures: Always de-energize and lock-out/tag-out (LOTO) the circuit before performing any installation, wiring, or maintenance work on the MCCB.
Product Applications
The 140G-H15I3-D16 MCCB is primarily used for protection and control in various three-phase industrial electrical systems:
- Main/Sub-Main Panel Protection: Used as the primary disconnecting means and overcurrent protection for entire electrical distribution panels.
- Feeder Circuit Protection: Protecting heavy-duty branch circuits that supply power to large equipment.
- Motor Protection: Used in conjunction with contactors/starters to provide thermal and short-circuit protection for high-horsepower three-phase motors.
- Transformer Secondary Protection: Protecting the secondary side of power transformers from overload and short-circuit conditions.
- Load Center Protection: Providing power distribution and protection in machinery and equipment enclosures.
- Commercial Buildings: Used in HVAC, lighting, and general power distribution systems requiring robust circuit protection.
Advantages: Foxboro, OVATION, TRICONEX, Allen-Bradley, ABB, Motorola, Siemens Moore, Ge Fanuc, Woodward, Bently Nevada and other major import brands!
We have the same series of models in stock. If you don’t find the model you need, please contact us and we will provide you with an official quotation！
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: Sweden
Price: Please contact us Product weight：0.515kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
