Product Name: XB4BD912R10K SCHNEIDER Central control module
Product details:
The XB4BD912R10K is a Complete Potentiometer from the Schneider Electric Harmony XB4 range, which is known for its robustness and suitability for industrial environments.
Product Parameters (Specifications)
| Parameter | Value |
| Product Type | Complete Potentiometer |
| Series | Harmony XB4 |
| Mounting Diameter | $\text{22 mm (0.87 in)}$ |
| Resistance (Ohmic Value) | $\text{10 k}\Omega \text{ (10000 Ohm)}$ |
| Potentiometer Characteristic | Linear |
| Tolerance | $\pm 10\%$ |
| Rated Power | $\text{1 W at } 70^\circ\text{C}$ |
| Rated Supply Voltage | $\le \text{30 V AC}, \le \text{42 V DC}$ |
| Element Material | Cermet |
| Operator Profile | Knurled knob, with white marking (0-10 scale) |
| Bezel Material | Chromium plated metal |
| Protection Degree (IP) | $\text{IP66, IP69, IP69K}$ (Dust-tight, protected against powerful and high-pressure water jets) |
| NEMA Degree of Protection | $\text{NEMA 4X, NEMA 13}$ |
| IK Degree of Protection (Impact) | $\text{IK06}$ |
| Operating Temperature | $-40^\circ\text{C}$ to $70^\circ\text{C}$ ($-40^\circ\text{F}$ to $158^\circ\text{F}$) |
| Mechanical Durability | 50,000 cycles |
| Connection Type | Screw clamp terminals (or Plug-in/Faston connectors) |
| Standards | UL 508, IEC 60947-1, CSA C22.2 No 14 |
| Net Weight | $\text{0.095 kg (0.21 lb)}$ |
Product Advantages (Key Features)
- High Robustness: Features a chromium-plated metal bezel and high ingress protection ratings ($\text{IP66/IP69/IP69K, NEMA 4X/13}$) making it suitable for operation in harsh industrial environments, including areas exposed to dust, moisture, and high-pressure cleaning.
- Reliable Performance: Cermet element material provides stable and durable performance, with a long mechanical life of 50,000 cycles.
- Ease of Installation: Designed for standard $\text{22 mm}$ panel cut-outs and offers quick and easy assembly/disassembly.
- Versatility: The $\text{10 k}\Omega$ linear characteristic makes it ideal for various control and adjustment tasks.
- International Compliance: Certified to major international standards (UL, CSA, IEC), ensuring broad applicability.
Precautions (Important Notes)
- Wiring: Ensure correct wiring polarity and do not exceed the specified rated supply voltage ($\le \text{30 V AC}$ / $\le \text{42 V DC}$) or power rating ($\text{1 W}$).
- Installation: Adhere to the recommended $\text{22.5 mm}$ mounting diameter for proper fit and sealing to maintain the $\text{IP}$ rating.
- Harsh Environments: While highly protected, the operating and storage temperature limits ($-40^\circ\text{C}$ to $70^\circ\text{C}$) must be respected.
- Chemical Exposure: Like many industrial components, this product may contain trace chemicals (e.g., Nickel compounds, Di-isodecyl phthalate (DIDP)). Follow all local safety and handling procedures. (In the US, refer to California Proposition 65 warnings).
Product Applications
The Schneider XB4BD912R10K potentiometer is primarily used as a human-machine interface (HMI) component to manually adjust an electrical signal for process control.
Typical applications include:
- Speed Control: Adjusting the setpoint for variable speed drives (VSDs) or motor controllers.
- Value Setting: Manually setting parameters like temperature, flow rate, pressure, or lighting levels in a control system.
- Remote Control: Providing a variable input signal to a PLC (Programmable Logic Controller) or other industrial controller.
- Position Sensing: Used in simple mechanical setups where a rotational position needs to be translated into a control voltage.
Advantages: Foxboro, OVATION, TRICONEX, Allen-Bradley, ABB, Motorola, Siemens Moore, Ge Fanuc, Woodward, Bently Nevada and other major import brands!
We have the same series of models in stock. If you don’t find the model you need, please contact us and we will provide you with an official quotation！
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: Sweden
Price: Please contact us Product weight：0.515kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
