Product Name: 1SAM360000R1011 ABB Central control module
Product details:
The ABB product 1SAM360000R1011 is an MS165-25 Manual Motor Starter (MMS).
Product Parameters (Specifications)
| Parameter | Specification (Typical Values) |
| Product Type | Manual Motor Starter (MMS) |
| Series | MS165 |
| Order Code (ABB Type Designation) | MS165-25 |
| Rated Operational Current ($\text{I}_e$) | 25 A (Maximum) |
| Setting Range (Thermal Trip) | Typically 18.0 – 25.0 A |
| Rated Operational Voltage ($\text{U}_e$) | Up to 690 V AC |
| Rated Impulse Withstand Voltage ($\text{U}_{\text{imp}}$) | 6 kV |
| Rated Short-Circuit Breaking Capacity ($\text{I}_{\text{cu}}$) | High, often $\text{I}_{\text{cu}} = 50 \text{ kA}$ at 400 V AC (Check specific datasheet for confirmation) |
| Motor Power (Typical at 400 V) | Varies depending on motor efficiency, typically up to 11 kW or 15 kW |
| Trip Class | Class 10 |
| Degree of Protection (IP Code) | IP20 (Terminals) |
| Mounting | DIN Rail |
| Connection Type | Screw Terminals |
Product Advantages (Key Features and Benefits)
- Motor Protection: Provides reliable protection for motors against overload (thermal trip) and short circuits (magnetic trip). This eliminates the need for separate fuses or thermal overloads in many applications.
- Disconnect Function: Serves as a manual ON/OFF switch for the motor, providing a visible isolation point for maintenance or emergency stop.
- Space-Saving Design: Its compact size is optimized for efficient use of space within control panels and electrical enclosures.
- High Short-Circuit Capacity: The MS165 series often features a high rated short-circuit breaking capacity ($\text{I}_{\text{cu}}$), ensuring reliable protection of the system and preventing damage even during severe fault conditions.
- Temperature Compensation: Features built-in temperature compensation to ensure the tripping characteristics remain accurate across a wide range of ambient temperatures.
- Integration Capability: Easily integrates with other ABB products like contactors (using corresponding connection kits) to form compact and coordinated motor starter combinations.
Precautions (Important Considerations)
- Setting Range: Always ensure the motor’s full-load current ($\text{I}_{\text{FLC}}$) is set correctly within the device’s adjustable 18.0 – 25.0 A range. Incorrect setting can lead to insufficient protection or nuisance tripping.
- Wiring and Torque: Use the correct wire size and ensure all terminal screws are tightened to the specified torque to prevent loose connections, overheating, and potential fire hazards.
- Short-Circuit Protection: While the MMS provides short-circuit protection, its breaking capacity must be coordinated with the upstream protective device (e.g., main circuit breaker) to ensure proper system protection.
- Environment: The device’s operating environment must adhere to the specified temperature and humidity ratings (typically IP20 protection requires installation in a suitable enclosure).
- Maintenance: Regularly check for dust accumulation or signs of overheating. Do not operate the device beyond its rated voltage or current.
Product Applications (Typical Usage)
The MS165 Manual Motor Starter is primarily used for control and protection of electric motors in various industries and equipment.
- Pumps: Used to start and protect motors driving centrifugal pumps, submersible pumps, etc.
- Fans and Ventilation Systems: For motors in HVAC systems, exhaust fans, and industrial ventilation.
- Conveyors: Protection of motors used in material handling systems and conveyors.
- Machine Tools: Suitable for machinery like drilling machines, lathes, and grinding machines.
- Compressors: Used in compressed air systems for motor control and protection.
- General Machinery: Any application requiring reliable ON/OFF switching and protection for three-phase or single-phase motors up to its power rating.
